Thunder T6 320W Quad Charger 73P-T6X4-Charger

The Thunder T6 Quad Charger has the ability to charge 4 batteries simultaneously. It has many special features detailed below.

Optimized operating software
The 320 watt multi charger features an AUTO function that sets the feeding current during the process of charging or discharging. It can prevent overcharging which may be dangerous to the battery or user. It will disconnect the circuit automatically and sound an alarm once it determines malfunction. All the programs of this charger are controlled through two way communications between user and software. It achieves maximum safety while minimizing confusion. These settings can also be fully configured by the user.

Internal independent lithium battery balancer
The T6 320W multi charger employs an individual cell voltage balancer. It isn?t necessary to connect an external balancer for balance charging.

Balancing individual cells during discharging
During the process of discharging, the T6 320W multi charger can monitor and balance each cell of the battery individually. If any abnormal voltages are detected the charger will sound the alarm and end its charging process.

Adaptable to various type of lithium Cells
The T6 320W multi charger is adaptable to various types of lithium batteries such as Li-Ion, LI-PO Lipo, and Li-Fe cells.

Fast and storage mode of lithium batteries
The T6 320W multi charger has the ability to fast charge and reduce the time required to charge a battery. The storage function can regulate the final voltage of the lithium battery required for optimal storage conditions to prolong battery life.

Maximum safety
Delta-peak sensitivity features allow the charger to detect peak voltage threshold and terminate the charging process for safety.

Automatic charging current limit
Ability to set the upper limit of the charging current when charging Nickel battery variants. It is useful for Ni-Mh batteries of low impedance and capacity in the auto charging mode

Capacity limit
The charging capacity is calculated as the charging current multiplied by time. If the charging capacity exceeds the limit, the process will be terminated automatically for the set maximum value.

Temperature Threshold
The batteries internal chemical reaction will cause the temperature of the battery to rise. If the temperature limit is reached, the charging process will be terminated. *This function required a temperature probe which is sold separately.

Cyclic charging/discharging
1 ? 5 cycles of continuous charge > discharge or discharge > charge is selectable for battery refreshing and balancing to stimulate battery function.

Data Store/load
5 batteries charge or discharge details can be stored for user convenience.

The Thunder T6 320W multi charger does not have an internal power supply so an external DC power of 11 ? 18 Volts will be required. A 12v battery from your car will suffice, however you do want to ensure you have ample capacity in your car battery so you are not left stranded because of this chargers powerful charging ability.

Specifications:
Operating Voltage Range: DC 11 ? 18 Volts
Power Source: AC mains power suppy > 400 Watts or 12V DC (Car Battery)
Charge Power: 80 Watts current is regulated accordingly
Example: 14.8v battery charge current approx 5.4A
22.2v battery charge current approx 3.6A
Discharge Power: 8 Watts by 4 ports. Current is regulated accordingly
Cell Count: Nickel Variant 1 ? 15 cells
Lithium Variant 1 ? 6 cells
Lead Acid Variant 1 ? 10 Cells 2 ? 20Volts
Current Drain for Balancing Lithium: 300mA
Charge Termination: NiCD/NiMH – Automatic, negative Delta Peak Method
Lead-Acid and Lithium ? Automatic, voltage dependent
Dimensions: 225.4 x 158.6 x 62.4mm
Net weight: 1.13Kg
